Specifications :

• Poles description : 1P, 1P + N, 2P, 3P, 4P
• Rated current : 0.5A, 1A, 2A, 3A, 4A, 6A, 10A, 13A, 16A, 20A, 25A, 32A, 40A, 50A, 63A
• Curve code : B, C, D
• Breaking capacity : 3kA, 5kA, 6kA, 10kA, 14kA, 15kA, 20kA, 25kA, 30kA, 40kA
• Rated opertaional voltage: <= 125V, <=250V, <=72V, <=500V, 12V, 12...250V,12...500V, 60V, 65V, 110V, 120V, 125V, 220V, 240V, 250V, 277V, 415V, 440V, 480Y/277V, 500V
• Network type: AC, DC

Benefits :

• Time-saving
• Easy to procure and install
• Meaningful commercial references
• Multi covers all standards for Industry application: UL/CSA for North America, IEC, EAC, CC, and others for the rest of the world. It allows a unique panel design.
• 70% of the packaging is made with recycled cardboard
• Green Premium products are RoHS and REACh compliant.
• Wide range of solutions that are customised to fit your efficiency and sustainability needs

Application :

• Machine
• Industry
