Compliance of standard	IEC61439 (1&6)
Conductor Material & Ratings	Copper 25A, 40A
Busbar Configuration	2P : ( 1-Phase + 100% Neutral ) + Integral Ground Earth 4P : ( 3-Phase + 100% Neutral )+ Integral Ground Earth 6P : ( 3-Phase + 100% Neutral + 1-Phase + 100% Neutral ) + Integral Ground  Earth 8P : ( 3-Phase + 100% Neutral + 3Phase + 100% Neutral ) + Integral Ground Earth
Rated Operational Voltage (Ue)	500V
Enclosure Material	Aluminium
Degree of Protection	IP 55
Plug-in Box	Upto 16A

Benefits :

• Low weight & compact Aluminium Housing saves space & Installation Time.
• Low smoke Halogen free flame retardant material makes it environment friendly & Reliable product.
• Ease of Installation between straight length, flexible elbows, end feed units, center feed Units etc. can be carried out by just push fit and screw tightening.
• Standardization of elements has made it easy for designing layout, selection and ordering.
• Flexibility in power distribution with range of Plug-in Boxes, simplifies complex Installations.
• Aesthetics
• Conformity to International standards.
