Compliance of standard	IEC61439 (1&6)
Conductor Material & Ratings	Copper 125A-1250A Aluminium 200A-800A
Busbar Configuration	3 Phase +  Integral Ground Earth 3 Phase + 100% Neutral+ Integral Ground Earth 3 Phase + 100% Neutral+100% Internal Earth+ Integral Ground Earth 3 Phase + 200% Neutral+100% Internal Earth+ Integral Ground Earth
Rated Operational Voltage (Ue)	1000V
Rated Impulse Withstand Voltage (Uimp)	12kV (1.2/50 µSec)
Enclosure Material	G.I.
Degree of Protection	IP 54
Plug-in Box	32A – 400A

Benefits :

• Flexibility in power distribution with Plug In points at every 500mm on either side of the resulting in reduced Installation cost and ease in upgradation by adding or relocating the Plug In boxes as per load locations.
• Wide range of Plug In boxes with provisions for Circuit breakers, Fuses, Switch Fuse Units and customized monitoring and metering makes it suitable for any application needs of distribution.
• Safety Features- Compliance of resistance to Fire propagation & Building Penetration, Compliance to severe seismic conditions, Interlocks in Plug applications & Ingress Protection.
• Reliability in terms of Mechanical strengths, Electromagnetic Compatibility, higher product life.
• Saving starts with Installation time, ease in relocation, replacement, addition and reusability.
• Aesthetical appearance after Installation.
• Conformity to International standards.
